Chapter 2 Using your C5te/F5te Using the SIM card slot 58

Using the SIM card slot

The SIM card slot holds one SIM card. You need to use a SIM card only if you’re using mobile

broadband on a GSM/UMTS/HSPA network. Contact your service provider for additional

information.

To insert a SIM card:

1. Turn off the tablet and remove the battery (page 45).

2. Locate the SIM slot door and open it.

Note: The SIM card slot and a diagnostic port are behind the SIM card slot door. The SIM

card slot is below the diagnostic port.

Smart card

Smart card reader

SIM card slot

Diagnostic port
