Chapter 2 Using your R12 Removing and replacing the battery 43

Removing and replacing the battery

Before you remove the battery, ensure that the tablet is plugged in, turned off, or in

Hibernate or Sleep mode. If you’re hot-swapping the battery (page 44), you can do so while

the tablet is on and running on battery power.

To remove the battery:

1. With the back of the unit facing you, hold and slide the battery latch to the left.

2. Insert your finger under the finger grip and lift up to remove the battery from the battery

compartment.

Press to view

charge level

Battery charge

indicator lights
